Shock Absorber Piston Banding Machine With Different Faces Identification Function

Shock Absorber Piston Banding Machine With Different Faces Identification Function

  • Shock Absorber Piston Banding Machine With Different Faces Identification Function
  • Shock Absorber Piston Banding Machine With Different Faces Identification Function
  • Shock Absorber Piston Banding Machine With Different Faces Identification Function
  • Shock Absorber Piston Banding Machine With Different Faces Identification Function
Shock Absorber Piston Banding Machine With Different Faces Identification Function
Product Details:
Place of Origin: ZHE JIANG , CHINA
Brand Name: XIAYI
Certification: ISO9001:2008
Model Number: XYJD-ZBJ0623
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: NEGOTIATION
Packaging Details: STANDARD EXPORTING PACKAGE WITH WOODEN BOX
Delivery Time: 3-4 MONTHS
Payment Terms: L/C, T/T
Supply Ability: 1 SET PER 3-4 MONTHS
Contact Now
Detailed Product Description
MACHINE TYPE: PRODUCTION MAIN COMPONENT: CYLINDER, MOTOR
DIMENSION: 800mm×1050mm×1250mm Rated Voltage: 380V
Total Power: 300W Air Pump Pressure: 0.5~0.8MPa
New Function: Deburr & Cutting Identification: Two Faces
High Light:

automatic grooving machine

,

shock absorber machine

Shock absorber piston banding machine with the function of different faces identification



This is the newest generation of automatic banding machine with the function of different faces



indentification and height cutting.



We can replace spare parts such as PLC, air cylinder and other parts according to the customer's



demand, some customers need the brand of Mitsubishi or need imported PLC, we can all satisfy their



demand. So we can design and produce this machine by OEM. This machine is very suitable to install in



shock absorber factory or powder metallurgy factory. We can also sell PTFE ring discs together with this



machine and our capability can reach more than 2 million pcs.



Technical parameters



Standard specification XYJD-ZBJ0623
Dimensions 1800*700*1700
Nominal capacity 400pcs-600pcs per hour
Voltage 380V
Powder supply 4-wire 3-phase
Tooling set-up 15 minutes
Air pressure 5 litre/cycle
Piston OD from 25mm to 46mm
PLC Siemens or others
Machine lead time 3 months
Machine spare parts 1 month
Machine spare unit available
Piston on table
Machinery drive SMC air cylinder





TEAM: We have a technical team to develop automatic and semi-automatic machines.


DIMENSION: We can get the pistons with PTFE banding on OD and can highly improve work efficiency



and lower the cost. Infrared ray can control the piston's outer dimension and we can assure the



dimension's consistency.


MOULD: We can make the mould by ourselves.


OPERATORS: Only need to put the powder metallurgy products on the table and take out of the finished



pistons from the table.



One person can operate several machines.



To assure the appearance of the products, we will improve to use long conveyer directly to work table

If you are interested in such machines, we can offer the detail information if you need. Our technical



persons can help to set up and debug the machines.



Our technic persons can help to set up and debug the machines.


Output:500-600 pcs pistons/hour



Electricity:380V


Tooling set up:15 minutes


Piston diameter:25mm-46mm


Piston height:12mm-20mm



Machine lead time:2 months



Tooling lead time:3 weeks



Machinery spares:2 weeks



Machinery spare set:available



Pistons in /out:on table



Infrared ray can control the piston's outer dimension and we can assure the dimension's consistency.


MOULD: We can make the mould by ourselves.


OPERATORS: Only need to put the powder matallurgy products on the table and take out of



the finished pistons from the table.



One person can operate several machines.





Competitive advantage:



superior hard chrome piston finish


maximum safety and stability


available for different types of vehicles



customer own design available


optimum corrosion resistance


superior design and engineering





Application:



All PTFE banding piston with different size rang from 20mm to 45mm





Picture show



Shock Absorber Piston Banding Machine With Different Faces Identification Function 0



Shock Absorber Piston Banding Machine With Different Faces Identification Function 1
